15" Two-Way Full-Range
Main System/Floor Monitor
Power Rating : 1500 W
Frequency Range (-10 dB) : Main: 42.9 Hz - 19.5 kHz
Monitor: 43.6 Hz - 19.3 kHz
Frequency Response (±3 dB) : Main: 58.1 Hz - 17.2 kHz
Monitor: 60.7 Hz - 16.7 kHz
Coverage Pattern : 90° x 50° nominal
Directivity Index (DI) : 10.2 dB
Directivity Factor (Q) : 10.4
Crossover Frequency : 1.7 kHz
Maximum SPL : Normal: 136 dB
Boost: 136 dB
Signal indicators : Limit: Yellow LED indicates peak output has been reached and dsp limiter is acting
Signal: Green LED indicates signal present
Power/Standby : Blue indicates system has power and ready to pass audio, Red indicates system has power but is in a power saving mode and will not pass audio.
Dynamic Control (Input) : dbx Type IV? limiter circuit
Input Impedance : 20K Ohms (balanced), 10K Ohms (unbalanced)
LF Driver : 1 x JBL 275G (15 in) woofer
HF Driver : 1 x JBL 2408H-2 37.5 mm (1.5 in) annular polymer diaphragm, neodymium compression driver
Enclosure : Asymmetrical, 18 mm, plywood
Suspension / Mounting : Dual 36 mm pole socket, 12 x M10 Suspension Points
Transport : 1 x injection molded handles with backing cup
Finish : Obsidian DuraFlex? finish
Grille : Powder coated, Obsidian, 16 gauge perforated steel with acoustical transparent black cloth backing.
Input Connectors : 2 x Balanced XLR / 1/4 inch input, 2 x unbalanced RCA input
Output Connectors : 1 male XLR balanced output
Dimensions (H x W x D) : 714.43 mm x 445.13 mm x 358.71 mm
(28.13 in x 17.52 in x 14.12 in)
Net Weight : 21.6 kg (47.5 lb.)
