15" Self-Powered Extended Low
Frequency Subwoofer System
The PRX715XLF, extended low frequency subwoofer was designed and engineered to provide sub bass frequencies with accuracy and power. Used as a single sub in a sub/sat system or in multiples as part of a scalable, large format sound reinforcement system, the PRX715XLF performs with extreme efficiency and control.
Power Rating : 1500 W
Frequency Range (-10 dB) : 37 Hz - 113 Hz
Frequency Response (±3 dB) : 44 Hz – 91 Hz
Internal Crossover Frequency : 100 Hz DSP controlled 48 dB filter slope
Loop out Crossover Frequency : 120 Hz analog 24 dB filter slope
Maximum SPL : 131 dB
Signal indicators : Limit: Yellow LED indicates peak output has been reached and dsp limiter is acting
Signal: Green LED indicates signal present
Power/Standby : Blue indicates system has power and ready to pass audio, Red indicates system has power but is in a power saving mode and will not pass audio.
Dynamic Control (Input) : dbx Type IV? limiter circuit
Input Impedance : 20K Ohms (balanced)
Polarity : normal or reverse polarity
LF Driver : 1 x JBL 2275H 15 in woofer
Enclosure : Rectangular, 18 mm & 25mm, plywood
Transport : 2 x injection molded handles with backing cup
Finish : Obsidian DuraFlex? finish
Grille : Powder coated, Obsidian, 16 gauge perforated steel with acoustical transparent black cloth backing.
Input Connectors : Two Balanced female XLR/ 1/4" combo connectors
Output Connectors : Two balanced male XLR connectors.
Dimensions (H x W x D) : 547.1 mm x 445.0 mm x 580.0 mm
(21.54 in x 17.52 in x 22.48 in)
Net Weight : 25.4 kg (56 lb.)
